AEQ Xpeak wired user panel

AEQ Xpeak wired user panels

INTERCOM USER TERMINALS WITH VOIP HD AND KROMA VOIP CONNECTIVITY

Audio is digitized and processed using 24 bits at 48 khz

Compatible with Conexia and Crossnet matrixes.

With Conexia: 20 Hz to 7KHz bandwidth. Up to 12 terminals per XC 19 card.

With Crossnet: 20 kHz to 4 KHz bandwidth. Up to 20 terminals per matrix.

Xpeak R and Xpeak D

Rack-mounted and desktop user panels with 8 programmable keys arranged in 4 different pages.

FRONT PANEL

At the front, we can find a “gooseneck” electret microphone and internal loudspeaker, a front USB connector for micro-headphones, 8 cross point keys-operating with the matrix, up to 4 pages per key can be programmed- and 2-axis, lever-type keys, allowing the user to control talk and listen and individual volumes for each communication cross point. Information is presented on two LCD graphic screens and RGB LEDs associated to the keys. Rotary encoder and configuration keys.

BACK PORTS AND CONNECTIONS

At the back, two VoIP ports for loop connection, USB (type B) connector for connection to headphones and PCs. GPIO:

connector with 2 optically coupled GPI and GPO and a power pin to supply external circuits. Internal power supply. Bluetooth: the device incorporates Bluetooth connection as an audio interface with a telephone or micro-headphone. It can combine  different audio signals arriving to the system from different devices. Eco-cancellation processing.

BELTPACK’s BACK PORTS AND CONNECTIONS

Ethernet VoIP port and PoE supply on a RJ45 latching connector. Back USB port for micro-headphones. Two-pin GPO output.

Xpeak_R rack user panels communicate as peers as well as with the rest of the family panels and interfaces, whether on the same local network or at remote locations with Internet or VPN access. Their 8 levers and 16 virtual keys simplify operation. Equipped with USB input for headsets and Bluetooth connectivity. Dual Ethernet connector: switch mode and daisy chain.
