AKG PCC160 Phase Coherent Cardioid Microphone
No reviews yet
SKU: MIC-AKG-PHC-PCC160
✓ In Stock (3 available)
♡ Sign in to save to WishlistThe PCC160 is a professional boundary layer microphone and an industry standard stage floor microphone. It´s capable of withstanding up to 120dB SPL without distortion. A bass-tilt switch allows the user to tailor the low-end response for particular applications. PCC® (Phase Coherent Cardioid®) technology uses diaphragms so small that any phase cancellations are above the audible range. This results in a wide, smooth frequency response free of phase interference. The PCC160 uses a supercardioid polar pattern that improves gain before feedback and reduces unwanted room noise from the rear.
The PCC160 Microphone from Crown Audio is a rugged phase coherent, surface mountable boundary microphone designed for accurate pickup and signal reproduction on stages, lecterns, news desks, conference tables and more. The microphone features a phase coherent, half-supercardioid pickup that minimizes pickup behind the capsule, resulting in high gain-before-feedback.
The PCC160's surface mounting increases directivity by 3 dB, and its increased sensitivity provides accurate signal reproduction at long range. A frequency response of 50 Hz to 18 kHz provides accurate signal reproduction, with minimal low-frequency noise and rumble. A "Bass Tilt" switch further reduces low-frequency noise. The PCC-160 microphone features a rugged steel body, able to withstand accidental abuse. The PCC160 requires 12-48V phantom power and includes a 15' cable with switchcraft TA3-female and XLR-male connections.
Industry Standard Stage Microphone
The PCC160's performance, range, and reliability make it a favorite for theatrical and performance capturing. Its increased sensitivity provides accurate signal reproduction, with frequency response tailored to give minimal low-frequency noise and rumble. A "Bass Tilt" switch further reduces low-frequency noise.
Half-Supercardioid Polar Pattern
The half-supercardioid polar pattern effectively eliminates signal at off-axis positions, such as orchestra pits.
Phase Coherent Pick Up
Boundary mounted miniature capsule provides accurate, phase coherent signal reproduction.
Low Profile, Rugged Design
The surface mountable, rugged steel construction is designed to withstand accidental abuse.
- Industry Standard Stage Mic
- Half-Supercardioid Polar Pattern
- Phase Coherent Pickup
- Rugged Design
| Audio frequency bandwidth |
50 - 18000 Hz |
| Equivalent noise level |
22 dB-A |
| Sensitivity |
22 mV/Pa |
| Signal to Noise |
72 dB-A |
| Recommended load impedance |
2000 Ohms |
